Object

Alternative title:

Klasa środowiska Matlab do szybkiej wizualizacji scenariuszy walk powietrznych

Abstract:

In this paper, the authorial Matlab Battlespace Visualization Class (MBVC) is proposed to plan, design, and compose the preliminary version of the desired computer animation, which can then be used both as a background for the discussion of the final composition and as an individual project for public presentation, providing a visual reference for missile-target engagement simulations. As a design tool, the MBVC allows us the combination of the advanced mathematical models of missile guidance loop elements (implemented in the discrete form as program scripts) with the capabilities offered by open, powerful, and flexible 3D graphical engine. As a visualization tool, the MBVC allows the designers to present their research findings in both an illustrative and informative way, providing a visual reference for the computer simulation. The class is freely available for scientific, engineering or educational use.

Place of publishing:

Warszawa

Publisher:

Wojskowa Akademia Techniczna

Date created:

2010 r.0

Date submitted:

2022-11-14

Date accepted:

2023-01-25

Date issued:

2023-12-31

Extent:

B5

Identifier:

oai:ribes-88.man.poznan.pl:2687

Call number:

doi:10.5604/01.3001.0054.1646

Electronic ISSN:

2720-5266

Print ISSN:

2081-5891

Language:

angielski

License:

click here to follow the link

Rights holder:

Wojskowa Akademia Techniczna

Starting page:

23

Ending page:

36

Volume:

14

Journal:

PROMECH

Keywords:

3D visualization, conceptual design, missile, aerial target, trajectory
