Object

Abstrakt:

The hereby work describes the examples of protection of light fighting vehicles armoured with additional reactive armours. The way of protecting of light fighting vehicles with the use of composite-reactive armours against penetration with HEAT projectiles (with a penetration ability of 300 mm RHA) and against small calibre (up to 14,5 mm) armour-piercing bullets are shown on the example of the BWP-1. Technical parameters of the CERAWA-1 armour and its assembly on BWP-1 are presented. The work also presents the results of static tests of several variants of reactive-passive panels of light fighting vehicles against PG-7 projectiles’ perforation at the angle of 60° and 72° from normal to the cassette surface. Depending on the surface mass of the light reactive-passive armour panels, different levels of damage to the armour witness plate were achieved.
; The hereby work describes the examples of protection of light fighting vehicles armoured with additional reactive armours. The way of protecting of light fighting vehicles with the use of composite-reactive armours against penetration with HEAT projectiles (with a penetration ability of 300 mm RHA) and against small calibre (up to 14,5 mm) armour-piercing bullets are shown on the example of the BWP-1. Technical parameters of the CERAWA-1 armour and its assembly on BWP-1 are presented. The work also presents the results of static tests of several variants of reactive-passive panels of light fighting vehicles against PG-7 projectiles’ perforation at the angle of 60° and 72° from normal to the cassette surface. Depending on the surface mass of the light reactive-passive armour panels, different levels of damage to the armour witness plate were achieved.

Miejsce wydania:

Warszawa
; Warszawa

Wydawca:

Wojskowa Akademia Techniczna ; Wojskowa Akademia Techniczna

Data utworzenia:

2010 r.0

Data wydania:

2010-12-30 ; 2010-12-30

Rozmiar:

B5 ; B5

Identyfikator:

oai:ribes-88.man.poznan.pl:2307

ISSN elektroniczny:

2720-5266 ; 2720-5266

ISSN drukowany:

2081-5891 ; 2081-5891

Język:

angielski ; angielski

Właściciel praw:

Wojskowa Akademia Techniczna ; Wojskowa Akademia Techniczna

Strona początkowa:

17 ; 17

Strona końcowa:

25 ; 25

Tom:

1 ; 1

Słowa kluczowe:

materials technology, explosion, explosive reactive armour, shaped chargeprojectile, armour protection ; materials technology, explosion, explosive reactive armour, shaped chargeprojectile, armour protection
