Object

Contributor:

Peter PERUN

Abstract:

The paper deals with modal analysis of the cylinders and tubes and their mutual comparison. Nowadays, modal analysis is a powerful method of describing the vibration properties. When we know own shapes and natural frequencies, we can predict e.g. behaviour of tubes under loading conditions. The tubes dimensions were taken as dimensions which are close to assault rifle barrels. The same dimensions were taken for cylinders. The cylinders and tubes as 3D objects were modelled and their lengths and thicknesses were modified. Modal analysis was performed by LS-DYNA software using FEM with iterative Lanczos method. In Tables 1-12, the natural frequencies for these cantilever beams and their corresponding own shapes with modification in fixing length for three different thicknesses are listed. In Figure 2 and 7-9, these natural frequencies versus modification in fixing length for three different thicknesses for corresponding modes are shown. In Figure 3-5 and 10-12, natural frequencies versus length of cylinders and tubes for three different thicknesses for corresponding modes are shown.

Place of publishing:

Warszawa

Publisher:

Wojskowa Akademia Techniczna

Date created:

2010 r.0

Date submitted:

2014-11-09

Date accepted:

2015-02-11

Date issued:

2015-06-30

Extent:

B5

Identifier:

oai:ribes-88.man.poznan.pl:2229

Call number:

doi:10.5604/20815891.1157770

Electronic ISSN:

2720-5266

Print ISSN:

2081-5891

Language:

angielski

Rights holder:

Wojskowa Akademia Techniczna

Volume:

6
